Cisco Router Module Cards NIM-2T Interfaces 2 X RS-232/449/530/V.35/X.21

Name: Cisco Router Module Cards NIM2T Interfaces 2 X RS232449530V35X21
Brand: Cisco
Price: 1 USD

Brand Name : Cisco

Model Number : NIM-2T

Certification : CE

Place of Origin : China

MOQ : 1Piece

Price : Negonation

Payment Terms : Western Union, T/T, Paypal

Supply Ability : 1000Piece/Month

Delivery Time : 2-3days

Packaging Details : Common Package

Condition : NIB and Used

Branch : Cisco

Type : Router Modules

Device Type : Serial adapter

Form Factor : Plug-in module

PN : NIM-1CE1T1-PRI

Contact Now

Cisco Router Module Cards NIM-2T Interfaces 2 x RS-232/449/530/V.35/X.21

NIM-2T Overview

Cisco® 4400 Series Integrated Services Router Network Interface Modules (ISRNIMs) provide highly reliable synchronous serial WAN connections for remote sites. These interfaces use well-known point-to-point WAN protocols such as High-Level Data Link Control (HDLC) and Point-to-Point Protocol (PPP) as well as Frame Relay, offering cost-effective virtualized WAN connections in both point-to-point and point-to-multipoint designs. You can mix and match NIMs to tailor cost-effective solutions for common networking solutions for low- and high-density WAN aggregation.

The Cisco Gigabit Ethernet High-Speed WAN Interface Card (HWIC) brings Gigabit Ethernet connectivity to Cisco Integrated Services Routers routers to accelerate applications such as Metro Ethernet access, inter-VLAN routing, and high-speed connectivity to LAN switches.The single-port Cisco Gigabit Ethernet HWIC provides Gigabit Ethernet optical and copper connectivity in a compact form factor for all Cisco Integrated Service Routers (ISRs).

NIM-2T Specification

NIM-2T Specification
General
Device Type	Serial adapter
Form Factor	Plug-in module
Networking
Ports	RS-232/449/530/V.35/X.21 x 2
Connectivity Technology	Wired
Data Link Protocol	RS-232, RS-530, X.21, V.35, RS-449, RS-530A
Data Transfer Rate	8 Mbps
Expansion / Connectivity
Interfaces	2 x RS-232/449/530/V.35/X.21
Miscellaneous
Compliant Standards	CISPR 22 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, EN50082-1, AS/NZS 60950-1, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, JATE, ICES-003 Class A, EN 61000-4-5, EN 61000-4-11, EN 61000-4-8, UL 60950-1, IEC 60950-1, EN 60950-1, FCC Part 15 A, CAN/CSA C22.2 No. 60950-1, VCCI Class A, EN 300386, CNS 13438
Dimensions & Weight
Width	3.5 in
Depth	7.2 in
Height	1.3 in
Environmental Parameters
Min Operating Temperature	32 °F
Max Operating Temperature	104 °F
Humidity Range Operating	10 - 90% (non-condensing)
Synchronous support	Yes
Synchronous maximum speed (per port)	8 Mbps
Serial protocols	EIA-232, EIA-449, EIA-530, EIA-530A, V.35, and X.21
Telecomm post, telephone, and telegraph (PTT)	• TBR1 and 2
Telecomm post, telephone, and telegraph (PTT)	• JATE digital
Safety	• UL 60950-1 (United States)
	• CAN/CSA 22.2, 60950-1 (Canada)
	• AS/NZS 60950-1 (Australia/New Zealand)
	• EN60950-1 (Europe)
	• IEC 60950-1 (International)
Immunity	• EN300386
	• CISPR24
	• EN55024
	• EN50082-1
	• 61000-4-2/3/4/5/6/8/11
Emissions	• FCC Part 15 Class A
	• ICES-003 Class A
	• EN55022 Class A
	• CISPR22 Class A
	• AS/NZSCISPR22 Class A
	• VCCI Class A
	• EN 300386
	• EN61000-3-2/3
	• CNS13438
Physical specifications	• Singlewide NI, no slot restrictions
Physical specifications	• Dimensions (H x W x D) 1.25 x 3.50 x 7.24 in. (3.18 x 8.89 x 18.39 cm)
Environmental specifications	• Operating temperature: 32 to 104°F (0 to 40°C)
	• Storage temperature: -4 to 149°F (-20 to 65°C)
	• Relative humidity: 10 to 90%, noncondensing

Business
