N9K-C93108TC-FX Overview
The Cisco N9K-C93108TC-FX Switch is a 1RU switch that supports 2.16 Tbps of bandwidth and over 1.25bpps. The 48 10GBASE-T downlink ports on the 93108TC-FX can be configured to work as 100-Mbps, 1-Gbps, or 10-Gbps ports. The uplink can support up to six 40- and 100-Gbps ports, or a combination of 1-, 10-, 25-, 40, 50-, and 100-Gbps connectivity, offering flexible migration options.
Quick Specs
Table 1 shows the Specs.
| SKU | N9K-C93108TC-FX |
| CPU | 4 cores |
| System memory | 24 GB |
| SSD drive | 128 GB |
| System buffer | 40 MB |
| Management ports | 2 ports: 1 RJ-45 and 1 SFP+ |
| USB ports | 1 |
| RS-232 serial ports | 1 |
| Power supplies (up to 2) | 500W AC, 930W DC, or 1200W HVAC/HVDC |
| RS-232 serial ports | 1 |
Product Details
Cisco N9K-C93108TC-FX provides the following features:
①Architectural Flexibility
②Architectural Flexibility
③High Scalability, Flexibility, and Security
④Intelligent Buffer Management
⑤RDME over Converged Ethernet – RoCE Support
⑥LAN and SAN Convergence
⑦Hardware and Software High Availability
⑧Purpose-Built Cisco NX-OS Software Operating System with Comprehensive, Proven Innovations
⑨Cisco Tetration Analytics Platform Support
⑩Cisco Network Assurance Engine (NAE)
Compare to Similar Items
Table 2 shows the comparison.
| Product Name | N9K-C93108TC-FX | N9K-C93180YC-FX | N9K-C9348GC-FXP |
| Ports | 48 x 100M/1/10GBASE-T and 6 x 40/100-Gbps QSFP28 ports | 48 x 1/10/25-Gbps and 6 x 40/100-Gbps QSFP28 ports | 48 x 1-GBASE-T ports, 4 x 1/10/25-Gbps SFP28 ports and 2 x 40/100 QSFP28 ports |
| CPU | 4 cores | 6 cores | 4 cores |
| System memory | 24 GB | Up to 32 GB | 24 GB |
| SSD drive | 128 GB | 128 GB | 128 GB |
| System buffer | 40 MB | 40 MB | 40 MB |
| USB ports | 1 | 1 | 1 |
| RS-232 serial ports | 1 | 1 | 1 |
N9K-C93108TC-FX Specification
N9K-C93108TC-FX Specification |
| Hardware performance and scalability |
| Ports | 48 x 100M/1/10GBASE-T and 6 x 40/100-Gbps QSFP28 ports |
| Downlink supported speeds | 100-Mbps and 1/10-Gbps speeds |
| CPU | 4 cores |
| System memory | 24 GB |
| SSD drive | 128 GB |
| System buffer | 40 MB |
| Management ports | 2 ports: 1 RJ-45 and 1 SFP+ |
| USB ports | 1 |
| RS-232 serial ports | 1 |
| Power supplies (up to 2) | 500W AC, 930W DC, or 1200W HVAC/HVDC |
| Typical power (AC/DC) | 276W |
| Maximum power (AC/DC) | 460W |
| Input voltage (AC) | 100 to 240V |
Input voltage
(High-Voltage AC [HVAC]) | 200 to 277V |
| Input voltage (DC) | –48 to –60V |
Input voltage
(High-Voltage DC [HVDC]) | –240 to –380V |
| Frequency (AC) | 50 to 60 Hz |
| Fans | 4 |
| Airflow | Port-side intake and exhaust |
Physical dimensions
(H x W x D) | 1.72 x 17.3 x 22.5 in.
(4.4 x 43.9 x 57.1 cm) |
| Acoustics | 64.2 dBA at 40% fan speed, 68.9 dBA at 70% fan speed, and 77.8 dBA at 100% fan speed |
| RoHS compliance | Yes |
| MTBF | 319,790 hours |
| Environmental properties |
| Operating temperature | 32 to 104°F (0 to 40°C) |
| Nonoperating (storage) temperature | –40 to 158°F (–40 to 70°C) |
| Humidity | 5 to 95% (noncondensing) |
| Altitude | 0 to 13,123 ft (0 to 4000m) |
S5735-L24P4S-A Overview
Establish Fast and Easy-to-use Network by Powerful Switches.
Choose top branded switches to accelerate your business, including Cisco, Huawei, Juniper, etc.
S5735-L24P4S-A is the Huawei S5735-L switch with 24 x 10/100/1000Base-T ports, 4 x GE SFP ports, PoE+. Huawei CloudEngine S5735-L is a series of simplified gigabit access switches that provide 12–48 flexible all-GE downlink ports and four fixed GE or 10 GE uplink ports. They are designed for enterprise campus network access and gigabit to the desktop. Built on next-generation, high-performance hardware and powered by Huawei’s Versatile Routing Platform (VRP), CloudEngine S5735-L switches feature flexible Ethernet networking, diversified security control, and support for multiple Layer 3 routing protocols — providing higher performance and more powerful service processing capabilities for networks.
Quick Spec
Table 1 shows the quick spec.
| Product Model | S5735-L24P4S-A |
| Forwarding Performance | 42 Mpps |
| Switching Capacity2 | 56 Gbit/s/336 Gbit/s |
| Fixed Ports | 24 x 10/100/1000Base-T ports, 4 x GE SFP ports |
| PoE+ | Supported |
Product Details
Figure 1 shows the front ports of S5735-L24P4S-A.
Note:
| ① | 24 10/100/1000BASE-T ports | ④ | One PNP button |
| ② | Four 1000BASE-X ports | ⑤ | One USB port |
| ③ | One ETH management port | ⑥ | One console port |
Figure 2 shows the back view of S5735-L24P4S-A.
Note:
| ① | Ground screw |
| ② | Jack for AC power cable locking strap |
| ③ | AC socket |
Supported Transceivers
Table 2 shows the recommended models.
| Model | Description |
| OMXD30000 | Huawei Optical Transceiver OMXD30000, SFP+, 10G, Multi-mode Module (850nm, 0.3km, LC) |
| OSX010000 | Optical Transceiver, SFP+, 10G, Single-mode Module (1310nm, 10km, LC) |
| SFP-GE-LX-SM1310 | Optical Transceiver, eSFP, GE, Single-mode Module (1310nm, 10km, LC) |
| OSXD22N00 | Optical Transceiver, SFP+, 10G, Multi-mode Module (1310nm, 0.22km, LC, LRM) |
| SFP-10G-USR | 10GBase-USR Optical Transceiver, SFP+, 10G, Multi-mode Module (850nm, 0.1km, LC) |
| OMXD30009 | Transceiver, QSFP+, 1310nm, 41.25Gbps, -7dBm, 2.3dBm, -11.5dBm, LC, SMF, 10 |
| SFP-10G-LR | Huawei Optical Transceiver SFP-10G-LR, SFP+, 10G, Single-mode Module (1310nm, 10km, LC) |
Compare to Similar Items
Table 3 shows the comparison.
| Product Model | S5735-L12T4S-A S5735-L12P4S-A | S5735-L24T4S-A S5735-L24P4S-A | S5735-L24T4X-A S5735-L24P4X-A | S5735-L48T4S-A | S5735-L48T4X-A S5735-L48P4X-A | S5735-L32ST4X-A |
| Forwarding Performance | 24 Mpps | 42 Mpps | 96 Mpps | 78 Mpps | 132 Mpps | 108 Mpps |
| Switching Capacity2 | 32 Gbit/s/336 Gbit/s | 56 Gbit/s/336 Gbit/s | 128 Gbit/s/336 Gbit/s | 104 Gbit/s/432 Gbit/s | 176 Gbit/s/432 Gbit/s | 144 Gbit/s/432 Gbit/s |
| Fixed Ports | 12 x 10/100/1000Base-T ports, 4 x GE SFP ports | 24 x 10/100/1000Base-T ports, 4 x GE SFP ports | 24 x 10/100/1000Base-T ports, 4 x 10 GE SFP+ ports | 48 x 10/100/1000BASE-T ports, 4 x GE SFP ports | 48 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports | 24 x GE SFP ports, 8 x 10/100/1000BASE-T ports, 4 x 10 GE SFP+ ports |
| PoE+ | CloudEngine S5735-L12P4S-A: Supported
CloudEngine S5735-L24P4S-A: Supported
CloudEngine S5735-L24P4X-A: Supported
CloudEngine S5735-L48P4X-A: Supported
Other: Not supported |
