QSFP 100G ER4L Juniper Router Transceivers QSFP-100G-ER4L 100GBASE-ER4-Lite Pluggable Module

Brand Name : Juniper

Model Number : QSFP-100G-ER4L

Certification : CE

Place of Origin : CHINA

Model : QSFP-100G-ER4L - Juniper Router Transceivers

sage : WAN, DCI, cloud overlay

Name : QSFP28-100G-ER4

Brand : Juniper

Wavelength : 1310 nm

Distance : 30 km 40 km SMF

Connector : LC duplex

Voltage source : 3.3 V

Contact Now

QSFP 100G ER4L Juniper Router Transceivers QSFP-100G-ER4L 100GBASE-ER4-Lite Pluggable Module

The Hilink 100GE 4WDM-40 40km QSFP28 Optical Transceiver (HL-QSFP28-4ER4C) is designed for use in 100 Gigabit Ethernet links up to 30 km without FEC or 40 km with FEC on Single Mode Fiber (SMF). These 4-channel optical signals will be optically multiplexed into a single fiber using 4 in 1 optical WDM multiplexing. The optical output power of each channel is maintained by a constant Automatic Power Control (APC). Transmitter output can be disabled from TX_DIS signal equipment and/or 2-wire serial interface.

Peculiarities:
Hot plug form factor QSFP28
4 channels full-duplex transceiver module
Supports 103.125 Gb/s. aggregate bit rate
4 channels DFB-LAN-WDM cooling transmitter
4 channels DRP ROSA
Internal CDR circuits on both receiver and transmitter channels
3.8 W maximum power dissipation
Maximum link length 30 km on SMF without FEC
Maximum link length 40 km per SMF with FEC
Duplex LC vessel
Built-in digital diagnostic functions
Operating body temperature range: 0 to 70 °C
One 3.3V power supply
RoHS-6 compliant (lead-free)

Scope:
100GBASE-ER4 Lite 100G Ethernet
100GE 4WDM-40 applications

QSFP 100G ER4L Juniper Router Transceivers QSFP-100G-ER4L 100GBASE-ER4-Lite Pluggable ModuleQSFP 100G ER4L Juniper Router Transceivers QSFP-100G-ER4L 100GBASE-ER4-Lite Pluggable Module

Part Number
740-071175
Speed
100 Gigabit Ethernet
Breakout Capable
No
Transceiver Type
QSFP28
Product Type
Optical Transceiver
Connector
Duplex LC
Monitoring Available
Yes
Digital Optical Monitoring
Yes
Standard: 100GBASE-ER4
MSA compliance (SFF, for e.g. SFF-8665)
SFF-8665
Diagnostic support
Yes
Minimum Junos/EVO OS release
17.3R1
Signaling rate, each lane
25.78125 ± 100 ppm
Transceiver input/output fibers
2
Transmitter wavelengths (range)
1294.53 nm to 1296.59 nm
1299.02 nm to 1301.09 nm
1303.54 nm to 1305.63 nm
1308.09 nm to 1310.19 nm
Receive lane wavelengths (range)
1294.53 to 1296.59 nm
1299.02 to 1301.09 nm
1303.54 to 1305.63 nm
1308.09 to 1310.19 nm
Transmitter output power, each lane (minimum)
-2.9 dBm
Transmitter output power, each lane (maximum)
2.9 dBm
Receiver input power, each lane (minimum)
-20.9 dBm
Receiver input power, each lane (maximum)
-3.5 dBm
Stressed receiver sensitivity (OMA) each lane (maximum)
-14.9 dBm (w/o FEC)
-17.9 dBm (w/ FEC)
Cable type
SMF
Core size/cladding
9/125 µm
Distance
40 km
Notes for Distance
Full 40km reach requires the use of FEC on the host platform. Without FEC, the reach is 30km.
Maximum Power consumption (W)
5.0 W (0° C to 70° C)
5.5 W (0° C to 75° C)
Operating Temperature (range)
0° C to 75° C
Typical Weight & Dimensions
Weight: 0.2 kg
Height: 13.5 mm
Width: 18.35 mm
Depth: 73.4 mm

QSFP 100G ER4L Juniper Router Transceivers QSFP-100G-ER4L 100GBASE-ER4-Lite Pluggable ModuleQSFP 100G ER4L Juniper Router Transceivers QSFP-100G-ER4L 100GBASE-ER4-Lite Pluggable ModuleQSFP 100G ER4L Juniper Router Transceivers QSFP-100G-ER4L 100GBASE-ER4-Lite Pluggable ModuleQSFP 100G ER4L Juniper Router Transceivers QSFP-100G-ER4L 100GBASE-ER4-Lite Pluggable ModuleQSFP 100G ER4L Juniper Router Transceivers QSFP-100G-ER4L 100GBASE-ER4-Lite Pluggable ModuleQSFP 100G ER4L Juniper Router Transceivers QSFP-100G-ER4L 100GBASE-ER4-Lite Pluggable ModuleQSFP 100G ER4L Juniper Router Transceivers QSFP-100G-ER4L 100GBASE-ER4-Lite Pluggable Module
